SCRUBBER
The scrubber (ACI - H2) of the "NOVITEK" trademark is intended for cleaning the air emissions of technological production from aerosols, solid suspended particles, harmful gases.
  • Air cleaning installation system
    The installation for wet cleaning of a gas-dust stream is located on lines for transporting technological emissions in supply and exhaust or recirculation ventilation systems, or directly in the working area. Depending on the technical tasks, a system for cleaning industrial emissions at the enterprise can be completed with a block of additional separation, sorption, chemical neutralization.
  • Wet cleaning efficiency of gas-dust flow
    Emissions cleaning system with water or degassing solutions, thanks to the patented technology of counter-current irrigation, when used, show better results than wet cyclones.

Scrubber design
Dimensions
Optional equipment
  • Technological tank - polypropylene pool with metal crate
  • Circulation pump
  • Dedicated automation module (Ip54 protection)
  • Power shield (protection Ip54)
  • Supply and exhaust fans
Scrubber efficiency
When choosing devices for cleaning industrial emissions, it is necessary to take into account the possibility of cleaning them from various types of pollutants simultaneously to the value of the maximum permissible concentration (MPC).
The effectiveness of the ACI is confirmed by the protocols of measurement results of accredited laboratories of industrial ecology of enterprises that monitor environmental protection and industrial sanitation.
Fill in this form and we will send you a questionnaire
By clicking on the button, you consent to the processing of personal data and agree to the privacy policy.
Examples of contaminants to be treated
Scrubbers can be used for any heat and mass transfer processes, as well as for capturing water-soluble gases at enterprises: the oil and gas industry, mining and processing factories, the production of building materials. Scrubbers can be used for cultural, leisure and sports centers for the purpose of disinfection and humidification in air recirculation systems.
Examples of completed projects
JSC "ECAT" for LLC "Service Catalyst Systems"
Moscow region, Stupinsky district, village Shmatovo Oct 2018
Air cleaning installations with a capacity of 30 000 m3/h are designed to purify a gas stream with SO2 impurities formed during catalyst regeneration. To neutralize harmful components in the stream to be cleaned, a circulating aqueous solution of soda ash is used in scrubbers.
Hydraulic filtration unit with a capacity of 30 000 m3/hour. Material - polypropylene homopolymer (PP-H). LxWxH: 3700 x 2165 x 5350 mm.
Fill in this form and we will send you a questionnaire
By clicking on the button, you consent to the processing of personal data and agree to the privacy policy.
